ELDES EWC1-B - КОМБИНИРАН (PIR+MW) БЕЗЖИЧЕН ДАТЧИК ЗА ВЪНШЕН МОНТАЖ - ЗАВЕСА КАФЯВ

ELDES EWC1-B - КОМБИНИРАН (PIR+MW) БЕЗЖИЧЕН ДАТЧИК ЗА ВЪНШЕН МОНТАЖ - ЗАВЕСА КАФЯВ
Цвят:
276,00 лв
В любими
Препоръчай
Отпечатай
Сравни
Въпрос за продукта
Детайли
Данни
Коментари
ХАРАКТЕРИСТИКИ
Детайли

КОМБИНИРАН (PIR+MW) БЕЗЖИЧЕН ДАТЧИК ЗА ВЪНШЕН МОНТАЖ - ЗАВЕСА - КАФЯВ - ELDES EWC1-B

1 – 2 – 3 and your home is completely safe!

Please welcome the curtain motion detector manufactured by our Europe partners, which is improved with ELDES wireless technology. You can easily add this device to your ELDES security system thus extending the security of your property from the outside. The device has PIR and microwave sensors included, that is why it detects any motion and immediately alerts you in case of the first signs of intrusion. Enjoy even greater security of  your property by extending your security system with this outdoor motion detector and easily control it with ELDES Security App.



Easily adaptable to any exterior

Everyone’s needs are different, so it sometimes takes time to choose the home exterior finish that meets your expectations. That is why you can choose your curtain detector based on the color of your window frame or exterior house walls. We have two options – traditional white and dark brown. By choosing the device of the right color, you will perfectly fit it into the exterior of your home!

Exceptional performance

ELDES wireless technology enables users to reach an impressive wireless range in open areas. Thick walls and multiple-store properties are no longer an obstacle. Curtain motion detector is made of waterproof material, which makes it resistant to any weather conditions or temperature changes. To keep your home even more secured, it is also very important to mention that the device has a very narrow curtain barrier (~7.5°), also the covered area is adjustable up to 12 m. Such flexibility helps to keep your home even more secured.

No unexpected guests

You can feel at ease knowing that your curtain detector precisely senses the first steps of intruders. You or a security company can be immediately alerted about the potential danger when PIR and microwave sensors are triggered. This curtain detector is designed to expand the security system’s capabilities and secure your property even if the windows are opened 24/7.



Изтегляне на ръководства: EWC1 - ръководство за инсталиране
EWC1 - Активиране и свързване


Данни
Производител
ELDES
Артикулен номер
EWC1-B
Коментари
ХАРАКТЕРИСТИКИ

Specifications

Wireless band ISM868 or ISM915*
Wireless communication range Up to 3000m (~9843ft) in open areas
Compatible with alarm systems ESIM384; Pitbull Alarm PRO
Power supply standard 3-10V
Max power supply 13,2 V
Medium consumption 8 uA
Max consumption 52 mA (6 V sensor in alarm)
Protection power sup. inversion Yes
Inhibition time between alarm 3-6 minutes (selectable by dip-switch)
Range IR max 12m (25°C)
Range MW max 12m
Low battery reporting Yes (selectable by dip-switch)
Range Test Yes (selectable by dip-switch)
Alarm Output C-NC-NA
Tamper Output C-NC-NA
Setting IR range Yes
Setting uW range Yes
Frequency MW 24,125 GHz
Vertical MW 80°
Horizzontal MW 32°
Vertical IR 90°
Horizzontal IR 7,5°
Warming time 60s
Operating temperature -20…+60°C
Weight 131g
Dimensions 129x40x48mm
*Depends on region.
