Product Description
Details
- Up to 5-ch IP camera accesses
- Incoming/Outgoing bandwidth: 100Mbps/80Mbps
- S+265, H.265, S+264, H.264 video formats
- Max. decoding capability: 16MP(30fps)×1 or 1080P(30fps)×5
- 5-ch synchronous playback
- Up to 10 TB capacity for each HDD
- Simultaneous HDMI and VGA outputs
- HDMI output at up to 4K resolution
- 1×RJ-45, 10/100 Mbps self-adaptive Ethernet port
- PoE interface, 4×RJ45, 10/100 Mbps self-adaptive Ethernet port
- S+ 265 compression effectively reduces the storage space by up to 75%
- Support cloud upgrade
Data
Manufacturer
TIANDY
Reviews
No themes available
Product Description
|
Video and Audio |
|
|
Access Channel |
5 |
|
Incoming Bandwidth |
100Mbps |
|
Outgoing Bandwidth |
80Mbps |
|
Resolution |
16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Preview Decoding Capability |
16MP(30fps)×1,8MP(30fps)×2, 6MP(30fps)×3, 5MP(30fps)×4, 4MP(30fps)×5, 3MP(30fps)×5, 1080P(30fps)×5, 720P(30fps)×5, 4CIF(30fps)×5 (AI on：16MP(30fps)×1,8MP(30fps)×2, 6MP(30fps)×2, 5MP(30fps)×3, 4MP(30fps)×4, 3MP(30fps)×5, 1080P(30fps)×5, 720P(30fps)×5, 4CIF(30fps)×5) |
|
Playback Decoding Capability |
16MP(30fps)×1,8MP(30fps)×2, 6MP(30fps)×3, 5MP(30fps)×4, 4MP(30fps)×5, 3MP(30fps)×5, 1080P(30fps)×5, 720P(30fps)×5, 4CIF(30fps)×5 (AI on：16MP(30fps)×1,8MP(30fps)×2, 6MP(30fps)×2, 5MP(30fps)×3, 4MP(30fps)×4, 3MP(30fps)×5, 1080P(30fps)×5, 720P(30fps)×5, 4CIF(30fps)×5) |
|
Third-party Camera Access |
ONVIF(Profile S/T); RTSP |
|
HDMI Output |
HDMI: 1024×768(60Hz),( 68365731,720P)1280×720(50Hz/60Hz), 1280×800(60Hz), 1280×1024(60Hz), 1440×900(60Hz),( 68365732,1080P)1920×1080(50Hz/60Hz),( 68365733,2K)2560×1440(30Hz),( 68365734,4K)3840×2160(30Hz) |
|
VGA Output |
VGA: 1024×768(60Hz),( 68365735,720P)1280×720(50Hz/60Hz), 1280×800(60Hz), 1280×1024(60Hz), 1440×900(60Hz),( 68365736,1080P)1920×1080(50Hz/60Hz) |
|
Multi-screen Display |
Simultaneous Output: VGA: 1/2A/2B/3/4/5/6 HDMI: 1/2A/2B/3/4/5/6 |
|
Audio Input |
1-ch, 3.5mm |
|
Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
|
Two-Way Audio |
1-ch, 3.5mm, using the audio input |
|
Compression Standard |
|
|
Video Compression |
S+265; H.265; S+264; H.264 |
|
Audio Compression |
G.711A; G.711U; AAC; ADPCM_D |
|
Stream Type |
Video; Video & Audio |
|
Network |
|
|
Network Protocol |
802.1X; ARP; DDNS; DHCP; DNS; Easy DDNS; FTP; HTTP; HTTPS; ICMP; IGMP; IPv4; IPv6; Multicast; NFS; NTP; PPPoE; QoS; RTCP; RTP; RTSP; SMB/CIFS; SMTP; SNMP v1/v2/v3; SRTP; SSH; SSL; TLSv1.2; TCP; UDP; Unicast; UPnP |
|
Moblie Client |
EasyLive Plus (Android, iOS) |
|
System Compatibility |
ONVIF(Profile S/T/G); RTSP; CGI; SDK; Milestone; P2P |
|
Web |
IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+ |
|
Recording Playback |
|
|
Multi-channel Playback |
5 |
|
Record Mode |
Manual Recording; Alarm Recording; Schedule Recording |
|
Storage Method |
Local HDD |
|
Backup |
USB storage device, Network |
|
Playback Function |
Play/Pause/Stop/Reverse/Slow/Speed/Backwards 30s/Forwards 30s/Full Screen/Backup (Video Editing)/Step/Digital Zoom/Instant Replay |
|
Dual Stream Record |
Yes |
|
Alarm |
|
|
General Alarm |
Motion Detection; Mask Alarm; Alarm Input(IPC); Alarm Input(NVR) |
|
Exceptions Alarm |
Video Loss; Network Disconnected; No Disk; Illegal Access; Disk group space alert; Disk Full; Disk R/W Error; Recording Abnormal; Abnormal found in smart of disk; Abnormal temperature of the disk; PoE Overload; Voltage Alarm(IPC); RTC Failure; IP Address Conflict; MAC Address Conflict; Disk Overload |
|
Intelligent Analytics |
|
|
AI by Camera |
Tripwire; Double Tripwire; Perimeter; Object Abandon; Object Missing; Running; Parking; Heatmap; Loitering; Video Abnormal; Audio Abnormal; On Duty Detection; Crowd Detection; Safety Helmet Detection; Electric Bicycle Detection; People Counting; Link to Tracking; Smoke and Fire Detection; Environmental Temperature Measurement; Face Detection; Human Body Temperature Measurement; Smart Alarm; Face Recognition; Human/Vehicle Classification |
|
AI by NVR |
Face Detection; Face Recognition; Tripwire; Double Tripwire; Perimeter; Smart Motion Detection |
|
VCA Search |
Early-warning Search; Behavior Search; Safety Helmet Search; Thermographic Retrieval; Duty Search; Electric Bicycle Retrieval; Face Search(Search by face attributes); Smart Motion Detection |
|
VCA Report |
Heatmap; People Counting; Face Statistics |
|
Face Detection |
|
|
Face Attributes Detection |
Gender; Age; Glasses; Face Mask |
|
Face Attributes Search |
Gender; Age; Glasses; Face Mask; Body Temp. |
|
Face Recognition |
|
|
Face Recognition Performance |
1-ch(1080P) video streams or 4-ch image streams |
|
Face Picture Library |
Up to 10 face libraries, up to 20000 base images |
|
Face Picture Comparison |
Yes |
|
AI Performance(AI by NVR) |
|
|
Perimeter/Tripwire Performance |
4-ch |
|
Smart Motion Dection Performance |
4-ch |
|
Storage |
|
|
HDD Capacity |
Up to 10 TB capacity for each HDD |
|
Disk Group |
1 Disk Group |
|
External Port |
|
|
USB |
2×USB2.0 |
|
HDMI |
1×HDMI(supports up to 4K resolution output) |
|
VGA |
1×VGA |
|
Network Interface |
1×RJ-45, 10/100 Mbps self-adaptive Ethernet port |
|
SATA |
1×SATA interface |
|
Alarm I/O |
4-ch, TTL inputs, 3mA, 3.3VDC; 1-ch, relay output, 1A, 24VDC |
|
PoE |
|
|
PoE Interface |
4×RJ45, 10/100 Mbps self-adaptive Ethernet port |
|
PoE Budget |
45W |
|
Power per PoE Port |
30W |
|
Standard |
IEEE 802.3 af/at |
|
General |
|
|
UI Language |
Simple Chinese; Traditional Chinese; English; Spanish; Korean; Italian; Turkish; Russian; Thai; French; Polish; Dutch; Hebrew; Arabic; Vietnamese; German; Ukrainian; Portuguese; Albanian; Indonesian; Greek |
|
Power Supply |
DC48V |
|
Power Consumption |
<10W(without HDD&without PoE) |
|
NetWeight |
0.9kg |
|
GrossWeight |
1.7kg |
|
Boundary Dimensions |
255(L)238(W)45(H)mm |
|
Package Dimensions |
385(L)80(W)280(H)mm |
|
Operating Temperature |
-10℃~+55℃ (+14℉~+131℉) |
|
Operating Humidity |
10%~90%RH (non-condensing) |
|
Storage Temperature |
-20℃~+60℃ (-4℉~+140℉) |
|
Package Kit |
Network Video Recorder*1; Screw Pack*1; Mouse*1; Power Adapter(DC48V 1.35A)*1; European Standard Power Cord*1; Instructions*1; Parts List*1 |
