A great way to provide additional protection to a property and avoid any uninvited guests in your territory. High reliability and multiple ways of remote control will satisfy and secure any kind of user.

To Favourites
Question about the product

Suitable in different objects

ESIM320 is designed for simple parking lot control of residential houses or gate control of private houses. ESIM320 allows to create up to 2000 unique users, which is enough for huge object service with just one gate controller! Area’s entry and exit may authorized either by a single phone call or by an individual schedule, and restricted according to a number of phone calls  or a specified deadline.



Here are some ESIM320 application examples that will make your everyday life easier:

  • Parking entrance control
  • Gate and garage door control of private areas
  • Control of electric appliances: lightings, watering, pumps, electric curtains, etc
  • Remote reboot of servers, networks

Different and convenient ways to control

Users have the opportunity to choose the most convenient way of managing gates:

  • Calls (control by a regular phone call or using a voice assistant (i.e.Google Assistant or Siri)).
  • Mobile App (Eldes Gates widget for Android users and Eldes Gates app for iOS users)
  • SMS (only for admins).
  • WEB platform (only for admins).
Valdymo būdai

Convenient remote administration

ESIM320 can have up to 5 admins at the same time. Remote configuration of the gate controller using the WEB platform and regular self-test ensure extremely easy maintenance. ESIM320 event log allows you to save and check a list of events in chronological order (up to 1000 entries total).

Flexible installation options

You can choose from 3 different versions of the ESIM320 protective housing. The EBOX enclosure is ideal for small indoor installations and different spaces, such as a home or a garage. The IP-66 is a waterproof case, making it ideal for outdoor installations. The DINRAIL enclosure is designed to control gates of a private house.

Untitled design (2)


Where gate controller can be used?


Parking entrance control

Gate control of private areas

Electrical appliance control: lighting, watering, pumps, etc.

Remote server, network reboot.

Article No.
Be the first to review this product!

Administrators up to 5
Users database up to 2000
Power supply 10-24 V 50 Hz ~ 200 mA max / 10-24 V 200 mA max
Current consumption in idle state w/o external devices connected up to 50mA
GSM modem frequency ESIM320 3G/2G EU 900/1800/2100MHz
GSM modem frequency ESIM320US 3G USA 850/1900MHz
Number of inputs 3
Number of outputs 2
Output type Relay
Maximum commuting output values 24V 50Hz ~ 0,5A / 24V 1A
Event LOG up to 1000 events
Dimensions 87×107×29 mm
Operating temperature range -20…+55 °C
Humidity 0-90% RH @ 0… +40°C (0-90% RH @ +32… +104°F) (non-condensing)
